9120 Gigabit Ethernet Media Converter 3-7
3.3 Models and Product Description
Model Extension Port Description
User Port: 1000BASE-SX, 850nm, MM, SC, 5.5dB, Full-duplex
9120-528-1-0 1000BASE-LX, 1310nm, SM, SC, 7dB, Full-duplex
for use in the 9101 powered LAN Chassis
9120-528-1-1 1000BASE-LX, SM, SC, 7dB, Full-duplex
120/240 VAC AC Adapter
User Port: 1000BASE-SX, 850nm,MM, SC, 5.5dB, Full-duplex
9120-628-1-0 1000BASE-LD, 1310nm Extended Distance DFB laser, SM, SC, 21dB, Full-duplex
for use in the 9101 powered LAN Chassis
9120-628-1-1 1000BASE-LD, 1310nm Extended Distance DFB laser, SM, SC, 21dB, Full-duplex
120/240 VAC AC Adapter
User Port: 1000BASE-SX, 850nm, MM, SC, 5.5dB, Full-duplex
9120-728-1-0 1000BASE-EX, 1550nm Extended Distance DFB laser, SM, SC, 21dB, Full-duplex
for use in the 9101 LAN Chassis
9120-728-1-1 1000BASE-FX, 1550nm Extended Distance DFB laser, SM, SC, 21dB, Full-duplex
120/240VAC AC Adapter
User Port: 1000BASE-LX, 1310nm, SM, SC, 7dB, Full-duplex
9120-828-1-0 1000BASE-EX, 1550nm Extended Distance DFB laser, SM, SC, 21dB, Full-duplex
for use in the 9101 LAN Chassis
9120-828-1-1 1000BASE-EX, 1550nm Extended Distance DFB laser, SM, SC, 21dB, Full-duplex
120/240VAC AC Adapter
Note: Typically the loss budgets are 2dB greater than listed.
