3 delhe-ua local management, Delhe-ua local management -3, 10/100 led indications when rx led is on -3 – Cabletron Systems Expansion module DELHE-UA User Manual
Page 41: 10/100 led indications when rx led is off -3

DELHE-UA Local Management
DELHE-UA User’s Guide
3-3
f
3.3
DELHE-UA LOCAL MANAGEMENT
For information concerning Local Management for the DELHE-UA, refer
to the host device manual.
A link exists if the associated port RX LED is on.
Table 3-2
10/100 LED Indications When RX LED Is On
LED
Color
Indication
10/100
Off
DELTX-UI is operating at 10 Mbps.
Green
DELTX-UI is operating at 100 Mbps.
No link exists if the associated port RX LED is off.
Table 3-3
10/100 LED Indications When RX LED Is Off
LED
Color
Indication
10/100
Off
No link or no cable attached. DELTX-UI
forced to 10 Mbps operation, or is
manually set to “auto-negotiate” mode.
Green
No link or no cable attached. DELTX-UI is
forced to 100 Mbps operation.
