Chapter 1: Introduction

1-2

DELHE-UA User’s Guide

1.1.2

Local Management

The DELHE-UA is managed through the host device in which it is
installed. For information concerning Local Management for the
DELHE-UA, refer to the manual for the host platform. For details on
obtaining the host platform manual, refer to Related Documentation in the
Preface.

1.1.3

Full Duplex Switched Ethernet

The optional Fast Ethernet (Port) Interface Modules for the DELHE-UA
can be configured to operate in Full Duplex Switched Ethernet mode.

1.1.4

LANVIEW Diagnostic LEDs

Cabletron Systems provides a visual diagnostic and monitoring system
called LANVIEW. The DELHE-UA LANVIEW LEDs help you quickly
identify transmit and receive status. Chapter 3 provides information on
the DELHE-UA LEDs and the DELTX-UI LED.

1.2

FEPIM OPTIONS

The FEPIM options for the DELHE-UA are listed in Table 1-1. Check the
Release Notes with the host platform for changes or additions to this list.

Table 1-1

FEPIM Options

Part Number

Connector

Media type

DELTX-UI

RJ45

category 5 unshielded twisted pair

DELFX-UI

SC fiber

multimode fiber

DELF3-UI

SC fiber

single mode fiber
