DELHE-UA User’s Guide 3-1
CHAPTER 3
LANVIEW LEDs
This chapter describes how to use the LANVIEW LEDs to monitor the
DELHE-UA status and diagnose DELHE-UA problems.
3.1 DELHE-UA LEDs
Refer to Figure 3-1 for the location of the DELHE-UA LEDs and
Table 3-1 for a description of the LED indications.
Figure 3-1 DELHE-UA LANVIEW LEDs
The terms flashing, blinking, and solid used in Table 3-1
indicate the following:
Flashing indicates an irregular LED pulse.
Blinking indicates a steady LED pulse (approximately 50% on
and 50% off).
Solid indicates a steady LED light. No pulsing.
DELHE-UA FEPIM 1 FEPIM 2
SP
Transmit (TX) Receive (RX) Transmit (TX) Receive (RX)
LEDs for FEPIM 1 LEDs for FEPIM 2
