This feature is effective in preventing the removal of the
battery from this device (which will render the unit inopera-
ble during the loss of AC power).
To activate the battery carrier tamper resist feature, remove
the unit from the trim plate, disconnect the AC quick con-
nector and locate the small cut-out in the middle of the
product label on the back of the unit. With a small screw-
driver, or similar tool, slide the
switch towards the top of the
label. (see Figure 6) The tamper
resist feature is now active and
the battery carrier can not be
opened until the tamper resist
feature is deactivated.
NOTE: Before activating the battery
carrier tamper resist feature, make
sure a fresh battery is installed in the
unit and that the battery carrier is properly closed. If the battery car-
FIGURE 6
Operating Instructions
POSTS
FIGURE 5A
FIGURE 5B
18
