Centro 6000 SI - Manual (Page 25)

2 3
EA
EA
EB
EB
ES
EM
ES
EA
13
Insert and Attach the Top rear granite support brace (EA) to the
Rear Island Wall (EB) using hardware C, D and E.
14
Insert and attach the Top Front Granite Support brace (ES) to the
Front Island Wall (EM), together with the Support Bracket, as shown
using hardware F, G and H. (Image shown is a rear view).
Fig. 13
Fig. 14
EC
EA
ES
15
Mount the Center Granite counter top (EC) to the Top Front and Rear
Support braces (ES + EA), as shown using hardware H, G, and F.
Fig. 15
