Centro 6000 SI - Manual (Page 22)

2 0
5
Align and connect the Front Island Wall (EM) to the Left and Right
Island Walls (ET + EI) using Hardware B, C, D, E as shown.
ET
ED
ED
EI
ET
EM
EI
4
Align and connect the Left (ET) and Right (EI) Island Walls to the Top
Support Bar (Ed) using Hardware C, D, and E as shown.
Fig. 4
Fig. 5
6
Invert the entire Entertainment Island Cart in this step to assemble
the Bottom Panel (EL).
At least two people are recommended
for this and all assembly steps. Align the Bottom Panel (EL) to
the bottom of the Entertainment Island Cart.
Note: Bottom Panel air vents should be on the right side of the
Island Cart.
EI
EL
EB
ET
EM
Fig. 6
Insert
