Centro 6000 SI - Manual (Page 21)

1 9
EK
EL
EK
EG EL
EK
Note: Hardware for Steps #1-21 are provided in
the Entertainment Island with Granite Countertop
hardware pack.
1
Assemble the Bottom Support feet (EK) (x4) and Nut (x4) to the Bottom
Panel (EL) as shown. Tighten all bolts. Turn Bottom Panel over.
EB
ED
2
Assemble the Wire Brace (EG) to the Bottom Panel (EL) using hard-
ware parts I & J.
Put the Bottom Panel assembly (EL) aside until Step 6.
3
Assemble the Top Support Bar (ED) to the Rear Island Wall (EB) using
hardware A, D, and E.
Fig. 1
Fig. 2
Fig. 3
