Controls, Lcd display – Sangean Package PR-D5 (V1) User Manual
Page 5
4
GB
Controls
Power button
AUX In signal
Band and Tuning step selection
Alarm set
CT Display
LCD display
Tuning / SET / AUTO SEEK knob
Volume Control
Preset buttons
FM Stereo / Mono switch
AUX IN socket
Earphone socket
DC input socket
Antenna
Battery compartment
2
3
5
7
5
4
3
2
0
9
4
6
8
LCD Display
Battery power
Stereo display
RDS display
Sleep and snooze status
Time set
Alarm display
Digital display
G
F
E
D
C
B
A
