CHAPTER 2. ANATOMY
5
Out 1
Effect output. Use a standard (TS) 1/4” instrument cable. Amp,
mixer, or DI goes here.
Out 2
Effect output. Use a standard (TS) 1/4” instrument cable. Amp,
mixer, or DI goes here. When using a mixer, hard pan the outputs left
and right.
Brake
Plug in a momentary or latching remote switch here. Pressing the
switch toggles the brake function on and off.
When the Brake is
turned on, the rotation will slow down and eventually stop. When the
brake is turned off, the rotation will speed back up.
Low Rotor Control
Plug in a TRS Low Impedance Expression pedal here. This allows
remote speed control of the low rotor independent of the high rotor.
High Rotor Control
Plug in a TRS Low Impedance Expression pedal here. This allows
remote speed control of the high rotor, independent of the low rotor.
You can use the to contol both high
and low rotors at the same time. The Polarity reversal function on
the Dual Expression pedal even allows one rotor to speed up while the
other slows down!
