FAT Drive - Users Guide


Welcome to the realm of Pigtronix! Your new FAT Drive is an analog distortion designed to impart warm,
tube sound overdrive while remaining transparent and true to your guitar’s tone. The FAT Drive is
sensitive to your playing dynamics and will respond musically no matter how soft or hard you push it.

The VOLUME control sets the overall output level. The GAIN control determines how much distortion the
FAT Drive adds to your sound. The “MORE” switch significantly increases the pedal’s gain when put in
the up position. The TONE knob controls a passive low pass filter. When the TONE knob is fully
clockwise, the filter is taken completely out of the circuit, for maximum brightness.

The 18VDC power supply that is included provides a huge amount of headroom and output level. Feel free
to experiment with running this pedal on a standard 9VDC (neg. tip) supply to get even more crunch at the
expense of some headroom and overall output.
