HXJZ-877 Mini Power Wireless Module User’s Manual

Optional Antenna:

Trouble and solve ways:

Item

Trouble

Trouble causes and solve ways

1

No

shine

of

Indicator light

a、Power Line badness touch .

b、Power is bad.

c、Power line meet in reverse, or diode of polarity protect is bad.

2

No transmitting or

receiving

a、Radio is badness touch with PC/terminal.

b、Radio with TTL/RS232/RS485 not match terminal.

c、RX frequency and TX frequency is not same.

3

High Bit error rate

a、antenna not match, or touch bad;

b、RF baud rate is not right.

c、Power supply ripple is too great.

4

Indicator

light

twinkling

a、Electromagnetism disturb in circumstance.

b、Same frequency disturb in the circumstance.
