HXJZ-877 Mini Power Wireless Module User’s Manual

receiving/transmitting the data from the interface. HXJZ-877 will automatically complete the other operations,

such as transmission/receiving conversion in the air, control, etc.

11. High reliability, small and light

Single chip radio- frequency integrated circuit and single chip MCU are use d for lessened peripheral

circuits, high reliability, and low failure rate.

12. Watchdog monitor

Watchdog monitors the inner function, so it can change the traditional product structure and improve the

product reliability.

Application of HXJZ-877

1.Appearance figure

HXJZ-877 figure

2. HXJZ-877 interface definition

TX/RX indicator light

Red: TX , Green :RX

User interface

Antenna socket
