HXJZ-877 Mini Power Wireless Module User’s Manual

1)User’s interface

HXJZ-877 have one interface of TTL/RS232/RS485, user can choose one .

HXJZ-877 standard interface: when the antenna upward, th e plastic socket gap upward, from left to

right,1-9 pin in turn, as follows:

(Remarks: Jack space between is 2.0 mm.)

Definition of connecting pins and connection method :

Item

no

PIN

Description

Level

Connected to the terminal

User terminal

Remarks

1

SLE

Sleep control (input) end

Low level to sleep,

High level awake

2

TXD/

A

(RS-485)

Serial data transmitting

end

RXD/ A (RS-485)

3

RXD/

B

(RS-485)

Serial data receiving end

TXD/ B (RS-485)

4

GND

Power supply/Ground

DGND/AGND

5

VCC

+5±0.5V

+5±0.5V

TTL

3V

user ’s

choose

6

I

2

No use

retain

7

I

1

No use

retain

8

O

2

No use

retain

9

O

1

No use

retain
