Hexin Technology HXSP-1004B 4-Port RS-485/RS-422 to Ethernet Serial Device Server User Manual

Page 4

background image

pin

MDI signal

MDI-X signal

1

TX+

RX+

2

TX-

RX-

3

RX+

TX+

6

RX-

TX-

4, 5, 7, 8

DC-IN: 5VDC power supply input

10/100M Ethernet: 10/100Base-T(X) Ethernet input and output

ACT LED indicator: Bright all along when connect power supply

LINK LED indicator: Bright all along when connected

RX/TX

LED

indicator:

Bright

all along

when

connect

to

the

network,

Flash

when

data transfer

1, 2, 3, 4: RS-232 port (HXSP-1004A),

RS-485/422 port (HXSP-1004B)

10/100Base-T Ethernet port

The 10/100BaseT(X) ports located on facility front panel. The PIN define of RJ45 port display as

follows, Connect by UTP or STP. The connect distance is no more than 100m. 100Mbps is used

100Ωof UTP 5, 10Mbps is used 100Ωof UTP 3, 4, 5.

RJ 45 port support automatic MDI/MDI-X operation. Can connect the PC, Server, Converter and

HUB by straight–though cable. Pin 1,2,3,6 Communication connect in MDI. 1→3, 2→6, 3→1,

6→2

are

used

as

cross-over

cable

in

the

MDI-X

port

of

Converter

and

HUB.

10Base-T/100Base-TX are used in MDI/MDI-X, the PIN define in the table as below.

1

8

Note: “TX±” transmit data±, “RX±” receive data±, “—”not use.

MDI (straight-through cable):

RJ45

8

1

TX+

3

TX-

6

RX+

1

RX-

2

3

RX+

6

RX-

1

TX+

2

TX-

MDI-X (cross-over cable):

RJ45

8

1

(RX+) TX+

3

(RX-) TX-

6

(TX+)

RX+

1

(TX-)

RX-

2

1

RX+ (TX+)

2

RX- (TX-)

3

TX+ (RX+)

6

TX- (RX-)

RS-232/485/422 interface
