Hexin Technology HXSP-1004B 4-Port RS-485/RS-422 to Ethernet Serial Device Server User Manual

Page 2

background image

Summary

4

ports

serial

device

servers

which

can

contact

with

network

fast.

it

provides

one

line RS-232/485/422 (RS-232: DB9M: RS-484/422 / 4 bits terminal block) and

1line 10Base-T, it can manage the disperse serial device or host computer by network, easily and

convenience. Setting or software upgrade by serial program group in applying. Support TCP, UDP,

ARP, ICM and DHCP protocol, support Windows Native COM and auto-contact function once the

network intermit.

In

addition,

4

ports

serial

device

servers

provide

the

managed

collocate

tools

that

based Windows flat roof. it can lead the user manage and configure facility step by step, all of

the setting can be done by network or serial .Support pass gateway and router, easily for user to set IP

address, Server and Client mode , size of data and so on, Can realize the serial device contact with

network

by simply setting.

Model name: HXSP-1004A, HXSP-1004B

Package checklist

While using this converter for the first time, please check whether the packaging is

intact, the random attachment is complete at first.

Serial server

User manual

Power adapter 5VDC

Straight network cable

Software CD-ROM

The accurate device is put in the apparatus, please pay attention to handling with care, avoid

violent vibration, so as not to influence equipment performance. If you find the apparatus has been

damaged or lost any part in the course of transporting, please notify the distributor of our company

or our company, we will solve properly for you as soon as possible.

Feature

Support RS-232/RS-485/RS-422

Support Socket application.

Support Sever and Client mode.

Support Windows/Linux COM serial driver mode.

Support TCP, UDP, ARP, ICMP and DHCP protocol

Support all of Windows Native COM and auto-contact function once the network blackout.

Support passing gateway and router.

All of the setting can be done by network and serial

Proper Serial auto-connection (On-the-fly)

Capability

Ethernet port

Standard: 10Base-T, 100Base-TX

Protocol: support TCP, UDP, APR, ICMP and DHCP protocol

Signal: Rx+, Rx-, Tx+, Tx-

Speed: 10/100Mbps

Working format: full or half of duplex

Work mode: support Server and Client mode

Port memory: 512byte

Transmit distance: 100m
