Interface protection: 1.5KV ESD

Interface type: RJ-45

Serial interface

EIA RS-232, RS-485, RS-422 standard

RS-232 signal: TxD, RXD, RTS, CTS, DTR, DSR, DCD, GND

RS-422 signal: Tx+, Tx-, Rx+, Rx-, GND

RS-485 signal: Data+, Data-, GND

Parity: None, Even, Odd, Space, Mark

Data bit: 7bit, 8bit

Stop bit: 1, 1.5, 2

Baud rate 150bps~230400bps

Flow control: RTS/CTS or non-flow control

RS485 data direction: ADDC (Auto data direction Control)

Loading: RS-485/422 side support 32 nodes (optional 128 nodes)

Transfer distance: RS-485/422 side: 1200m, RS-232 side: less than 15m

Serial line protect: 1500W surge protect, 15KV magnetic isolation

Interface type: RJ-45

Power supply

Power supply input: 5VDC

Consumption:300mA

Environment

Operating temperature: -20℃~60℃,

5~95% RH

Storage temperature: -25℃~85℃,

5~95% RH

Appearance

Color: Black

L×W×H: 160mm×91.2mm×30.4mm

Material: Iron (shell)

Weight: 230g

Panel

1. HXSP-1004

HXSP-1004A is 1 port 10/100Base-T(X) to 4 ports RS-232, HXSP-1004B is 1 port 10/100Base-
T(X)

to 4 ports RS-485/422, the appearance is the same.

This manual is related to the following products:
