OFNA Racing 91849 DigiPeak 3 - Manual (Page 5)

S
S
In Li-Po mode
MIN. CHARGE current is 0.3A
MAX. CHARGE current is 4A
1 CELL
2 CELL
3 CELL
MIN. DISCHARGE current is 0.3A
MAX. DISCHARGE current is 2A
Press the S(START) button within 2
sec. to go back to the MAIN MENU.
start charging
Charging Process Discharging Process
LI-PO 'CHARGE'
C=2.0A 7.4V
LI-PO CHARGE
C=2.0A 7.4V
LI-PO 'DISCHARGE'
D=0.5A END=6.0V
LI-PO CHARGE
C='2.0A' 7.4V
LI-PO DISCHARGE
D='0.5A' END=6.0V
LI-PO CHARGE
C='4.0A' 7.4V
LI-PO CHARGE
C=2.0A '3.7V'
LI-PO CHARGE
C=2.0A '7.4V'
LI-PO CHARGE
C=2.0A '11.1V'
LI-PO DISCHARGE
D='2.0A' END=6.0V
LI-PO DISCHARGE
D=2.0A END='6.0V'
LI-PO DISCHARGE
D=2.0A END='3.0V'
+
+
-
-
+ -
+ -
+ -
+ -
4 CELL
LI-PO CHARGE
C=2.0A '14.8V'
LI-PO CHARGE
C=2.0A 14.8V
Please Reconfirm
the BAT. TYPE.
Press the S(START) button within 2
sec. to go back to the MAIN MENU.
Please Reconfirm
the BAT. TYPE.
CHG 00 : 00 00000
LI+ 2.00A xx.xxV
start discharging
DHG 00 : 00 00000
LI- 2.00A xx.xxV
+ -
+
-
LI-PO DISCHARGE
D=2.0A END='9.0V'
LI-PO DISCHARGE
D=2.0A END=12.0V
+
-
LI-PO DISCHARGE
D=2.0A END='12.0V'
+ -
5
