Assembly of the tires and wheels – OFNA Racing Ultra MBX Pro User Manual
Page 30
Assembly of the right and left hand side
are the same.
R
R
15072
Wheel Nuts
Blue
ASSEMBLY OF THE TIRES AND WHEELS
INSTANT
GLUE
* Apply instant glue into
the groove of the wheel.
86062
X Equal Pin
Tire
81095
Inner Sponge
86026
V Spoke Wheels
White
ASSEMBLY OF THE WHEELS ONTO
FRONT KNUCKLE ARM AND REAR HUB
More Wheels
86024 - V Spoke Wheels, Blue
86025 - V Spoke Wheels, Lime
86024 - V Spoke Wheels, White
86024 - V Spoke Wheels, Orange
86024 - V Spoke Wheels, Gray
86024 - V Spoke Wheels, Yellow
