OFNA Racing Ultra MBX Pro User Manual
Page 13
30151
Upper arm Shaft
90021
3mm
E-Ring
90021
3mm
E-Ring
R
R
0
1
36905
Caster Angle
Adjuster
* o
change
the caster angle .
use adjuster t
Caster angle will
become bigger.
Caster angle will
become less.
ASSEMBLY OF THE CASTER ADJUSTER
ASSEMBLY OF THE FRONT UPPER
ARMS INTO GEAR BOX
Assembly of the right and left hand side
are the same.
90018
3 x 25mm
Cap Screw
36610
Shock Support
Option:
36507
Alum. CNC
Shock Spacer
