Assembly of the radio tray onto chassis – OFNA Racing Ultra MBX Comp User Manual
Page 20
34070
Rear Stiffener
30287
Alum.
Fuel Tank Post
Pressure Nipple
X7
3x10mm
Flat Head Hex
Screw
3x10mm
Flat Head Hex
Screw
3x10mm
Flat Head Hex
Screw
3X10mm
Hex Screw
X4
3X10mm
Hex Screw
3X10mm
Hex Screw
3x10mm
Flat Head Hex
Screw
3X12mm
Hex Screw
3X12mm
Hex Screw
3X12mm
Hex Screw
X2
40109
Fuel Tank
JP-08
Fuel Tank
Pressure Nipple
ASSEMBLY OF THE RADIO TRAY ONTO CHASSIS
94003
94003
94019
94003
94004
94004
94004
94019
94019
94019
