OFNA Racing Ultra MBX Comp - Manual (Page 13)

94022
3x18mm
Flat Head Hex Screw X2
94022
3x18mm
Flat Head
Hex Screw
94029
4x25mm
Flat Head Hex Screw X2
94029
4x25mm
Flat Head
Hex Screw
X2
X2
X1
94027
4x16mm
Flat Head Hex Screw
94027
4x16mm
Flat Head Hex
Screw
94019
3x10mm
Flat Head Hex Screw
94019
3x10mm
Flat Head
HexScrew
Set triangle marks in
the direction shown
in Fig.(1)
36730
Cap Joint
90026
5x5mm
Set screw
X1
5x5mm
Set screw
30630
6x13x5mm
Ball Bearing
30010
Gear Box
30630
6x13x5mm
Ball Bearing
30130
Bevel Gear
(Small)
Step 2
Step 1
90018
3X25mm
Cap Screw
90018
3x25mm
Cap Screw
30010
Gear Box
Front Cover
36610
Shock Support
Steel
30351
Toe-in Cams
30351
Rear Lower
Arm Holder
ASSEMBLY OF THE REAR GEAR BOX
ASSEMBLY OF THE REAR SHOCK TOWER
34033
Rear Body
Post
34019
Shock Tower
1
Degree 1.5
Degree
Fig.1
Use rear tor-in adjustere.
* place 5X4 mm
set screw in D cut
90026
