OFNA Racing Ultra MBX Comp - Manual (Page 12)

3x8mm
Screw
X2
X2
3x8x0.8mm
Washer
3x8mm Screw
3x8x0.8mm
Washer
30341
Stabilizer Ball
30403
6mm Ball
40199
Stabilizer
Ball End
40199
Stabilizer
Ball End
M3x8mm
Set Screw
3x18mm Screw
M3x8mm Set Screw
X2
X2
3x18mm
Screw
A
B
M3x3 Set Screw X2
M3x3
Set Screw
* Cut the plastic as shown.
36905
Caster Adjuster
CLIP IN THE CASTER ADJUSTER
Assembly of the right and left hand side
are the same.
Assembly of the right and left hand side
are the same.
ASSEMBLY OF THE FRONT STABILIZER
34027
Stabilizer
* o change
the caster angle .
use adjuster t
*Caster angle will
become bigger. *Caster angle will
become less.
Caster Adjuster
Caster Adjuster
Caster Adjuster
94002
94002
94006
94035
94033
94033
94006
94035
