ASSEMBLY OF THE SERVO SAVER ONTO THE FRONT GEAR BOX

ASSEMBLY OF THE GEAR BOX AND REAR SHOCK STAY

ASSEMBLY OF THE REAR LOWER ARMS

94003
3x10mm
Hex Screw

.....x2

3x15mm

3x10mm

40039

3mm

94021
3x15mm
Flat Head Screw

.....x2

94041
M3 Nylon Nut

Step 1

Step 2

30630
6x13x5mm Ball Bearing

.....x2

94029
4x25mm Flat Head Screw

.....x2

94036
5x5mm Set Screw

.....x1

94005
3x16mm Hex Screw

.....x2

94022
3x18mm Flat Head Screw

.....x2

Apply
Grease

cre

30630

30010

30082

30130

30630

5x5mm

3x18mm

4x25mm

3x16mm

30010

34009

3mm

36171

4x10mm

Ensure
Free
Movement

3mm

30351

3mm

4x16mm

34035

94027
4x16mm
Flat Head Screw

.....x2

36870
4x10mm Set Screw

.....x2

*A 4x10mm set screw is
used to adjust ride-height.

34035
