ASSEMBLY OF THE CLUTCH ONTO ENGINE MOUNT AND MUFFLER

ASSEMBLY OF THE ENGINE ONTO CHASSIS

Step 1

Step 2

94041
3mm
Nylon Nut

.....x4

10185

31990

30480

3mm

3x16mm

.....x4

30481
3x16mm
Cap Screw

*Slide the 3mm nylon
nut into engine mount.

ASSEMBLY OF THE CLUTCH

Step 3

Step 1

Step 2

5x9x0.3mm

3x7mm

3x5mm

34110

cre

*Use washers or shims for
the clutch bell,
this may vary with different
engines.

Tighten

35238

35242

35253

.....x1

10099
5x9x0.3mm Washer

34110
5x10x4mm Ball Bearing

10099
3x8x0.8mm Washer

10099
3x5mm
Cap Screw

.....x1

35958
5x8x2.5mm Ball Bearing

10402

*Use note book paper to set gear backlash
between spur gear and clutch bell gear,
applying pressure while retightening the
engine.
*If the space is not correct the spur gear
will be damaged.

Note book Paper.

10114

3x8mm

35958

3x5mm

34110

31989

(For two speed.)

(Fortsingle speed.)
