OFNA Racing Late Model Dirt Oval User Manual

Page 7

ASSEMBLY OF THE FRONT KNUCKLE ARMS

ASSEMBLY OF THE FRONT KNUCKLE AND FRONT SUSPENSION ARMS

ASSEMBLY OF THE FRONT STABILIZER

Step 2

Step 1

94036
5x5mm
Set Screw

.....x2

36903

36904

36905

36901

5x5mm

36052

30656

36053

36055

Do Not
Over Tighten

36053
8x16x5mm
Ball Bearing

.....x4

36055
2.5x16.8mm Pin

.....x2

Assembly for both right and left side.

Do Not
Over Tighten

*Notice the direction of the
plastic washer.

36905

36903

Assembly for both right and left side.

Makes two rods for left and right
hand-side.

3x16mm

3x8mm

40199

40029

30341

30403

94005
3x16mm
Hex Screw

.....x2

94035
3x8mm
Set Screw

.....x2

30403
6mm Ball

2.5mm
Hex Wrench

Approx. 3mm

Approx. 4mm

5mm Tool

Make steering
ball move
smooth.

* "L" for left side.

*Insert the drive shaft
before assembly.
