OFNA Racing Late Model Dirt Oval User Manual

Page 10

background image

16

17

18

ASSEMBLY OF THE REAR SUSPENSION ARMS

ASSEMBLY OF THE REAR SUSPENSION ARMS

ASSEMBLY OF THE REAR STABILIZER

6

Assembly for both right and left side.

36053
8x16x5mm
Ball Bearing

.....x4

36055
2.5x16.8mm Pin

.....x2

36055

94036
5x5mm
Set Screw

.....x2

Ensure
Free
Movement

Assembly for both right and left side.

*Approx. 20mm

1:1

3mm

3x18mm

3x25mm

3mm

94006
3x18mm
Hex Screw

.....x2

.....x4

36850
7mm Ball

94041
3mm
Nylon Nut

.....x4

94008
3x25mm
Hex Screw

.....x2

Step 1

Step 2

36861

40065

36850

40065

Assembly for both right and left side.

3x16mm

Makes two rods for left and right
hand-side.

30403

3x8mm

40029

30341

40199

.....x2

30403
6mm Ball

94005
3x16mm
Hex Screw

.....x2

94035
3x8mm
Set Screw

.....x2

36850

5x5mm

30656

36053

36082

36053

31304

31307

31305

31306

*Notice the direction of the
plastic washer.

Step 1

Step 2

2.5mm Hex
Wrench

Approx. 2mm

Approx. 3mm

34054

5mm Tool

*Insert the drive shaft
before assembly.
