4assembly of the gear box and front shock stay – OFNA Racing Late Model Dirt Oval User Manual

Page 6

ASSEMBLY OF THE GEAR BOX AND FRONT SHOCK STAY

Step 1

Step 2

Apply
Grease

Scre

94011
4x16mm
Hex Screw

.....x2

30631

30010

30082

30130

30631

5x4mm

30631
6x13x5mm
Ball Bearing

.....x2

94029
4x25mm
Flat Head Screw

.....x2

94036
5x4mm
Set Screw

.....x1

94009
4x10mm
Hex Screw

.....x2

94023
3x25mm
Flat Head Screw

.....x2

36171

4x16mm

30160

36890

3mm

4x10mm

36870
4x10mm
Set Screw

.....x2

Ensure
Free
Movement

36890

3mm

3x25mm

4x25mm

4x10mm

30010

34043

ASSEMBLY OF THE FRONT LOWER ARMS

ASSEMBLY OF THE FRONT UPPER ARMS

36905

3mm

36640

94010
4x12mm
Hex Screw

.....x2

Ensure
Free
Movement

30654

36900

36905

3mm

4x12mm

*Caster angle will
become bigger.

*Caster angle will
become less.

Caster Adjuster

Ensure
Free
Movement

90021
3mm
E-Ring

.....x4

90021
3mm
E-Ring

.....x2

*A 4x10mm set screw is
used to adjust ride-height. Approx. 3mm

2.0mm Tool
