ASSEMBLY OF THE TRANSPONDER

ASSEMBLY OF THE TRANSPONDER

CUT THE RADIO CASE
(ONLY IF YOU HAVE PERSONAL TRANSPONDER)

Step 1

Step 2

Step 3

Step 1

Step 2

Personal trasponder (Not Included)

*Bend the cut part as picture shown.

3x12mm

3x8mm

94002
3x8mm
Hex Screw

.....x1

94004
3x12mm
Hex Screw

.....x2

94001
3x5mm
Hex Screw

.....x2

3x5mm

21

Knife

*Connect transponder wire
to channel 3 on receiver.
