OFNA Racing Jammin SCRT Electric User Manual
Page 22
54
55
56
ASSEMBLY OF THE WHEEL BEAD LOCKS
ASSEMBLY OF THE TIRE ONTO FRONT KNUCKLE AND REAR HUB
ASSEMBLY OF THE BODY
18
94057
2x6mm
Hex Screw
.....x44
40865
40865
4mm Nylon Nut
.....x4
Cut Out
40937
*A
ire and wheel.
ssembled t
Step 1
Step 2
Cut Out
2x6mm
40951 GRAY
40939 RED
40940 BLUE
*Cut out the body as picture shown.
*Make four tires that are the same.
SCRT DECAL SHEET 40938
40949 TIRES
40952 SPONGE
