31
5. Activity Icon
This icon indicates data activity between your Modem and the network.
OFF No data activity
Blinking arrows Data passing through your Modem
Steady arrows Modem is in connect or dormant state
6. Info Text Messages
There are various Info messages displayed in this window. These messages
inform you various statuses of your Modem.
No Device No devices connected to Modem
Searching… Your Modem is searching EV-DO or
1X networks for services
No Service Your Modem cannot detect any
network after search completed
Ready Your Modem is ready for network
connection
Device Detected
Connected Your Modem is connected to the
network
Connected
(Dormant) Your Modem is connected to the
network but is inactive
Battery Low
Battery Error
7. Connect/Disconnect Button
This button allows you to connect or disconnect your Modem to the network. It
will toggle between two states Connect and Disconnect. The Disconnect button
appears only when your Modem is currently in the Connected or Connected
(Dormant) modes. This allows you to turn off the sessions by disconnecting your
Modem from the service network. In all other Modem modes, the Connect
button will appear. Note that although the Connect button appears, the Info Text
message must show “Ready” before you can connect to the network.
8. Menu/X/- Buttons
The Menu button gives you access to additional advanced Modem setting and
configuration such as Network Setup, Options and Status selection. The X
button exits AxessManager utility. Note that exiting the utility does not mean
