Wilbur Curtis TLXG2 - Manual (Page 3)

5
6
7
8
9
10
11
12 13
14
15
16
17
18
19
20
21
1
1A
2
3
4
5
5A
5B
6
6A
6B
7
8
WC-56008
WC-56019
WC-2003
WC-2002
WC-2005
WC-2027
WC-2025
WC-2030
WC-2012
WC-2010C-101
WC-2017
WC-1939
WC-1938
LID ASSY, TLXG15 Z-TYPE
LID ASSY, TLXG1 Z-TYPE
CAP PLUG, VENTED 44
CAP SHIELD W/CLEANOUT
WASHER, SHIELD CAP 1/8”
GLASS, GAUGE 10” TLXG15
GLASS, GAUGE 8” TLXG1
GLASS, GAUGE 13” TLXG2
SHIELD, GAUGE GLASS 10” TLXG15
SHIELD, GAUGE GLASS 8” TLXG1
SHIELD, GAUGE GLASS 13” TLXG2
NUT, FLANGED TLS-2
SHANK, PLASTIC CAP-T2
Index
Nº
Part
Nº Description
9
10
11
12
13
14
15
16
17
18
19
20
21
WC-2006-101
WC-2004
WC-1905
WC-1906
WC-3705
WC-1841
WC-64067
WC-3699
WC-2426
WC-56013
WC-36076
WC-38281
WC-5680
WASHER, .188 x .188
SHIELD BASE
NUT, WING PLASTIC
C’ RING .917 x .760 x .090
KIT, FAUCET REPAIR
FAUCET, ESP BLACK
GUARD, FAUCET TLXG15 Z-TYPE
INSULATION, TUBE SLIT 3/8” THK
ELBOW, SILICONE TLXG15 Z-TYPE
BASE ASSY, SERVER
BRUSH, GAUGE GLASS
LABEL, DECAF
DRIP TRAY, THERMOSERVER
Index
Nº
Part
Nº Description
Illustrated Parts List
Illustrated Parts
ThermoPro Gravity Pot
3
All parts are common amoung 1, 1½ and 2 gal-
lon servers, except where noted.
