5
8.25”
(21.0 cm)
12.25”
GAS INLET
(31.1 cm)
(60.3 cm)
(51.8 cm)
23.75”
27.625”
(70.2 cm)
9.25”
(23.5 cm)
20.375”
14.625”
(37.1 cm)
1.5”
WATER INLET
(3.8 cm)
2.25”
ELEC. INLET
(5.7 cm)
WB-14 Rough-In Drawing
WB-14 -11
PROBE
ORANGE
WHITE
WHITE
BLUE
BLACK
T1
T2
T3
T4
WATER LEVEL
CONTROL BOARD
7/3/07
INLET VALVE
2 GPM 10W/120V
14 GAL 115V GAS WATER BOILER
115V, 3A, 2W+G, 60HZ
POWER
CORD
POWER SUPPLY
120V/60Hz
GREEN
WB-14 Wiring Diagram
