Before mounting a whipper plate,
place a dab of food grade lubri-
cant in the rear hole of the seal.
Shaft seals should be replaced
with the groved side facing out-
ward. Place a dab of food grade
lubricant in the rear hole of the
seal, as shown below.
MODEL
PCGT4
PCGT5
ONE
ONE
CONFIGURATION OF CANISTERS
ON PCGT MODELS
10 LB. CANISTER
P/N CA-1113-06L
10 LB. CANISTER
P/N CA-1113-06R
5 LB. CANISTER
P/N CA-1112-06
ONE
ONE TWO
THREE
View of PCGT Unit with Side Panel Removed, Showing
Location of Triac and Control Board.
47
10
11
6
7
45
6A
Illustrated Parts
