3
Steps to Programming
Your Curtis Generation 3 cappuccino
dispenser is Factory Pre-Set for Optimum
Performance. Programming for all models is
identical except where noted.
Entering the Programing Menus
Press and hold STOP/WASH for
about ten [10] seconds. Display will
read Program Menus,(See Illustra-
tion).
Manual Dispense (Factory Set to Manual Dispense)
Press  or > to go to Manual Dispense Select.
Press  to go to Manual Dispense Select Station.
Choose the station and press, the display will read Saving Complete! To select another station for manual dispense,
press  to go to Manual Dispense Select Station or press > to continue to the next menu.
Dispense By Time (Factory Setting OFF)
The next screen is Dispense By Time < Select >. Press  to select a station. Select the station and the screen will
read To Begin Press Push. Press desired dispense button. Hot water will start to dispense and screen will display
To Finish Press Push. When Push is pressed, time will be saved and you will exit back to Dispense by Time screen.
Continue with additional selections or press > to continue to the next menu.
Temperature (Factory set at 190°F – Cold Cappuccino Units Set at 96ºF)
Press  and screen will show Tank Temperature. Temperature is programmable from 80°F to 204°F in 2-degree incre-
ments. Press < or > to go up or down in degrees. Select desired temperature and then  to set. Press > to continue
to the next menu.
Powder % Ratio (Factory set at 60%)
Press  and the screen will display Powder % Ratio Select Station. Press desired station. Powder ratio is program-
mable from 0% (Hot Water) to 100%, in 5% increments. Press < or > to increase or decrease ratio and then press
 to set. Press > to continue to the next menu.
Valves should not be field adjusted to change product strength.
Product strength adjustments should be done through programming on the front panel only.
Service Call (Factory Set to 1-800-000-0000 x0000)
Press  to display number and press  change number or > to move places and EX to exit when complete This
number will be displayed during a Heating system SENSOR ERROR or a WATER ERROR. Press > to continue to the
next menu.
Banner Name (Factory Set to Curtis)
Press  to display letters, press  to change letters or > to move places and EX to exit when complete.
This feature allows up to 14 letters to be programmed for company name or regional name. Programming all blanks
disables Banner Name. Press > to continue to the next menu.
Model Select
Press  to select, < or > to select desired model (PC-1, -2, -3, -4, -5) . Press  to set and exit program mode.
Exit
Press  to select, exits program mode and returns unit to operation.
