Wilbur Curtis GEMSS - Manual (Page 6)

6
* Recommended parts to stock.
1
1A
2
2A
3
3A
3B
4
5
6
6A
7
8
9
10
10A
11
12
12A
13
14
15 WC-58117
WC-5450
WC-37122*
WC- 854
WC-39436
WC-39432
WC-39434
WC-3417
WC-29050*
WC-61396
WC-5452
WC-8559 *
WC-39448
WC-1809 *
WC- 847 *
WC- 883
WC-2402P
WC-37130*
WC- 884-102
WC-1501
WC- 103 *
WC-3528 COVER, TOP
COVER, TOP (OLDER UNITS)
KIT, DUMP VALVE RIGHT
VALVE, BREW DUMP RIGHT 240V 12W
LABEL, CONTROL PANEL 3 BATCH
LABEL, CONTROL PANEL 1 BATCH
LABEL, CONTROL PANEL 2 BATCH
BREW CONE,ASSY W/SPLASH POCKT
SPRAYHEAD, AFS-AMBER
COVER, FRONT GEMSS TALL
COVER, FRONT (5/2010 AND EARLIER)
RELAY, SOLID STATE INCL HEAT SINK
LABEL, BOTTOM WRAP GEMSS
FAUCET, HOT WATER
VALVE, INLET 2GPM 120V 10W
VALVE, INLET 2 GPM 240V 10W
ELBOW, 3/8NPT x 3/8FLARE PIPE PLTD
KIT, VALVE BYPASS
VALVE, BY-PASS, 220V NON-ADJUST
FUSE HOLDER ASSY W/5A FUSE
SWITCH, TOGGLE NON-LIT DPST 25A
LEG, 4” ADJUST 3/8-16 THREAD
PART № ITEM № DESCRIPTION
16
17
18
18A
19
20
21
22
22A
23
24
24A
25
26
27
28
28A
29
30
31
32 WC-5451
WC-43089
WC-37102*
WC- 975
WC-3765L*
WC-37132*
WC-2977-101K
WC-37176*
WC- 728
WC-5853-102
WC-62035
WC-62034
WC-5502-01*
WC- 522*
WC-43055
WC- 906-04*
WC- 904-04
WC-5350
WC-43801
WC-1438-101*
WC-5231 * WARMER DECK - NO HTG ELMTS
GASKET, 1.00 OD x .625 ID X .03 THK
WARMER ELEMENT
WARMER, ASSY CMPLT 100W 220V
KIT, VALVE REPAIR
KIT, VALVE REPAIR
KIT, SPRAYHEAD FITTING
KIT, UCM & LABEL INSTRUCTIONS
CONTROL MODULE, 220V TP2S/TP2T
COVER, TOP HEATING TANK GEN USE
TANK, COMPLETE GEMSS W/ULTEM
TANK, COMPLETE GEMSS DV ULTEM
KIT, LIQUID LEVEL PROBE
THERMOSTAT, RESET
SHOCK GUARD, RESET THERMOSTAT
HEATING ELEMENT, 2000W 220V
ELEMENT, HEATING 1.6KW 120V
TUBE, ½” ID x 1/8W SILICONE
SHOCK GUARD, HEATING ELEMENTS
SENSOR, TEMP HEATING TANK
COMPOUND, SILICONE 3/4 OZ TUBE
PART № ITEM № DESCRIPTION
19
5
6
7
22
29
21
20
2
32
31
8
9
10
11
12
13
14
15
16
18
24
1
2
3
4
17
Illustrated Parts List – GEMSS
