ILLUSTRATED PARTS LIST
ALPHA GT
ITEM PART Nº DESCRIPTION
1 WC-58117 COVER, TOP ALP1/ALP3GTL/ALP3GTR/ALP5GTW
1A WC-58019 COVER, TOP ASSY ALP2GT
1B WC-58066 COVER, TOP ALP2W/ALP6GTW
1C WC-6812 WARMER, TOP ASSY 120V ALP3GT/ALP5GTL/ALP5GTR
1D WC-61132-101 COVER, TOP ASSY ALP4GT
1E WC-8619 WARMER, TOP ASSY ALP6GT
2 WC-2962 FITTING, SPRAYHEAD PLT’D
3 WC-37061* KIT, LABEL & UCM ALPHA 1GT CURTIS
3A WC-37062* KIT, LABEL & UCM ALPHA 2GT CURTIS
3B WC-37063* KIT, LABEL & UCM ALPHA 3GT CURTIS
4 WC- 102* SWITCH, TOGGLE SPST 25A 125/25OVAC RESISTIVE
4A WC- 103 SWITCH, TOGGLE DPST 25A 125/25OVAC RESISTIVE
5 WC-2401 ELBOW, 1/4 x 3/8 FLARE
6 WC- 826L* VALVE, INLET 1.0 GPM 120V
6A WC- 856 VALVE, INLET 1.0 GPM 220V
7 WC- 889-101* VALVE, DUMP LEFT 120V 12W
7A WC- 860 VALVE, LIQUID DISPENSING LEFT 22OVAC 12W
8 WC-29025 SPRAYHEAD, PURPLE ENHANCED FLOW
8A WC-29050 SPRAYHEAD, AMBER (OPTIONAL)
9 WC-37252 KIT, HOT WATER FAUCET REPLACEMENT ALPGT
10 WC-1806 SEAT CUP, SILICONE (USE WITH WC-1809 FAUCET)
11 WC-5970 COVER, BACK CTR WRAP ALPHA GT
12 WC-3518 LEG, GLIDE 3/8”-16 STUD SCREW
12A WC-3503 LEG, SCREW BUMPER (3/8”)
13 WC-37135* KIT, WARMER ELEMENT 100W 120V W/PLATE
13A WC- 975* WARMER ASSEMBLY COMPLETE, 100W 220V
14 WC-3621-101 BREWCONE, 7⅜” BLK
14A WC-3316 BREWCONE, ASSY S.S. (OPTIONAL)
15 WC-5310* TUBING, 5/16 ID SILICONE GEN USE
16 WC-5853-102 COVER, TOP HEATING TANK
16A WC-5851 LID, HEATING TANK (OLDER UNITS)
17 WC-37278* KIT, LIQUID LEVEL PROBE GT
18 WC-1438-101* SENSOR, TEMPERATURE
19 WC-5231* COMPOUND, SILICONE 5 OZ TUBE
20 WC- 917-04* HEATING ELEMENT, 1.45kW 120V W/JAMNUTS & WSHRS
21 WC-523* THERMOSTAT, MANUAL RESET 120/240VAC 25A 220º F MAX
21A WC-522 THERMOSTAT, HI LIMIT HEATER CONTROL DPST 277V 40A
22 WC-6289 HEATING TANK CMPLT, 120V W/WC-523 HIGH LIMIT THERM.
22A WC-6285 HEATING TANK CMPLT, 120/220V (DUAL VOLTAGE)
22B WC-6267 HEATING TANK, COMPLETE, 220V
23 WC-3765L* KIT, VALVE REPAIR (USE WITH WC-826, WATER INLET VLV)
24 WC-3763* KIT, VALVE REPAIR (USE WITH WC-889, DUMP VALVE)
25 WC-8591 CAPACITOR, X2 USED ON ALL ADS (NOT SHOWN)
26 WC- 165* SWITCH, WARMER RED SPST ALP5GT/10GT (NOT SHOWN)
27 WC-8556 HEAT SINK ASSEMBLY DV ALPHDS D5OOAP TCTD/PTTD
* SUGGESTED PARTS TO STOCK
