Back Panel Diagram
① AC Inlet
② AC Umbilical Cord Female Outlet
③ AC Umbilical Cord Male Inlet
④ Fuse Port
⑤ Optical Output(Top) and Input(Bottom)
⑥AES/EBU Output(Top) and Input(Bottom)
⑦Coaxial BNC Output(Top) and BNC Input(Bottom)
⑧ USB 2.0 Input
⑨ XLR Balanced Outputs
⑩ RCA Unbalanced Outputs
1 2
4
5
6
3
8
9
7
10
WDS-1
WTP-1
