Night Optics Falcon 10x Gen 3 Gated Long-Range Night Vision Binocular - Manual (Page 4)

TECHNICAL SPECIFICATIONS
General
Magnification 10x
Field of view 5°
Objective lens
Focus 250 mm
Aperture ratio 1:2.0
Focusing 10 m to ∞
Eyepiece
Focus 15 mm
Diopter setting +4 to -4
Mechanical characteristics
Dimensions 18” L x 5.3” W x 6” H
Weight 6.6 lbs (1.9 kg)
Electric parameters
Power source AA Batteries (x2)
Voltage 3v
Continuous operation time
- Passive mode 1 hour
- Active mode (with IR illuminator) 5 hours
IR illuminator
Type IR light diode
Power of light radiation 5, 25,75 mW
Field of View 40°
Field of View w/ magnification lenses 4°-10°
Radiation wave length 805 or 940 Nm
Operation conditions
Operating temperature range -40°F to 122°F
Relative humidity 0% to 98%
PACKAGE CONTENTS
1 LRB-7 Binoculars
1 Lens cap
2 Rubber eyepiece guards
1 Case
Operators Manual
3
