SM4M/SM16M Storage Module User Guide
A-2
Table A-1 *9 Mode Commands for Storage Module
Command
Display
Description
1
01:0000
RESET: enter 248 to erase all data and
programs and reset pointers. While erasing,
the SM does a simple check of the memory.
The time required to reset an SM4M is
approximately 1 minute; the SM16M takes
nearly 3 minutes.
01:XX
The number of megabytes of data storage
(4 for SM4M, 16 for SM16M).
03:01
INSERT FILE MARK at the position of the
SRP if a file mark wasnt the last thing placed
in the data. 1 indicates that the mark was
inserted, 0 indicates that it was not.
4
04:XX
DISPLAY/SET MEMORY
CONFIGURATION: enter the appropriate
code to change configuration: 0=ring, 1=fill
and stop.
5
DISPLAY STATUS (A to advance to each window):
01:ABCD
Window 1:
AB
Not used
CD
Total number of megabytes
02:ABCD
Window 2:
ABC
Not used
D
No. of Programs stored (Max=8)
03:ABCD
Window 3:
A
Errors logged (up to 9)
B
Not Used
C
Memory Config. (0=ring, 1=fill & stop)
D
Memory Status (0=not full, 1=full)
04:XXXXX
OS signature (0 if bad OS)
6
06:00
Not used
7
07:00
Not used
8
08:00
Not used
9
DISPLAY ADDRESSES OF CONNECTED STORAGE
MODULES:
XXXXXXXX
1 = occupied, 0 = unoccupied
87654321
(Addresses 8-1 from left to right)
10
CHANGE ADDRESS
10:0X
X is current address, enter yA to change and
then display address (where y=1...8).
