SM4M/SM16M Storage Module User Guide
2-4
2.3.1 Burst Data with CR10/10X, CR23X Dataloggers
Entering a ‘3’ for the third digit in parameter 4 of Instruction 23 selects the
Storage Module as the destination for the Burst data. All SMs connected should be
set to Fill and Stop and have consecutive addresses. The Burst data will be sent to
the first available (lowest addressed) Storage Module, followed by the next lowest
addressed, and so on.
2.3.2 Burst Data with 21X Dataloggers
To send Burst Measurement (Instruction 23) data to the Storage Module from the
21X, set the Destination option (parameter 4) to 2 for serial port output at 76,800
baud.
