8
Loading the Battery
The Concord Eye-Q Go LCD uses one 3V (CR123) lithium battery.
Loading the Battery:
1. Locate the battery door on the bottom of the
camera.
2. Slide the battery door outwards, as indicated by
the arrow and lift the battery door to open.
(fig.1.1)
3. Insert the 3V (CR123) lithium battery with the
positive terminal (+) toward the inside of the
battery compartment.
4. Close the battery door, press down on it and slide
it towards the center of the camera until it snaps
into place.
Note: Take extra care in opening or closing the battery door so as to
prevent the battery from falling out.
Checking the Battery
The camera has a battery indicator that shows the current battery level.
FULL
Battery is full and
ready for use.
LOW
Battery is low in
power and it needs
to be replaced soon.
fig.1.1
fig.1.2
