Metalfab Model DBI Volumetric Screw Feeder - Manual (Page 4)

2. Remove the four (4) bolts (Part #3) and pull the tube forward until it
disengages the screw.
To remove the screw (Part #4), the tube must be removed as indicated above
then:
1. Loosen the set collar on the bearing (Part #5)
2. Loosen set screw on jaw coupling (Part #6) so it will fall from the screw
shaft when the screw is pulled forward.
The hopper (Part #8) may be removed by undoing the bolts (Part #9) and lifting
vertically off the trough assembly (Part #10).
Re-assemble by reversing the above procedures.
When inquiring about any feeder, always refer to the Serial Number
stamped on the Metalfab nameplate.
Metalfab Service
Metalfab, Inc.
Prices Switch Road
P.O. Box 9
Vernon, NJ 07462
Phone (973) 764-2000 * Fax (973) 764-0272
Email: [email protected]
