Cam Lock
G
Attach Fixed Shelf (F) to
Middle Panels (D) and (E)
with Cam Locks.
(See figure 1)
Slide Back Panel (G)
into position.
Figure 1
STEP 1
STEP 2
Assembly Instructions 2/5
Cam Lock Screw
B
H
Insert Cam Lock Screws
into the pre-drilled holes
of Top (A), Middle Panels (D), (E)
and Base (H).
A
H
D
E
E
D
F
G
IMPORTANT
* Do not tighten up all the screws until each part is properly assembled.
* You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
* After assembly, item must be level to work properly. Use the included adjustable levelers to level.
