Home Styles 5543-10 - Manual

Part List
Hardware List
E.
Base
1 pc.
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
A.
Top
1 pc.
H.
Plinth
1 pc.
Tools required for assembly : Phillips screwdriver
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
[email protected]
For assembly see instructions in carton 88 5543 102
88 5543 101
Bermuda
Entertainment Credenza
F.
Shelf
4 pcs.
Cam Lock
19 pcs.(+4 extra)
Cam Lock Screw
19 pcs.(+1 extra)
Adjustable Pin
24 pcs.(+1 extra)
Pull Handle
2 pcs.
Machine Screw
2 pcs.
Magnet
2 pcs.
Wood Screw
for Magnet
4 pcs.(+1 extra)
Wood Screw
for Back Panel
12 pcs.(+1 extra)
Tools recommended for assembly :Level
I.
Back Panel
2 pcs.
J.
Back Panel
1 pc.
