B&C Technologies M720 Dryer Control (DE, DP, DI Series) - Manual (Page 50)

Table 7.4: Connector J10 Pinout
Pin Point Function
1 Output 1 Common
2 Output 1 Cooldown Damper
3 Output 2 Status
4 Output 3 Heat Recirculation Damper
5 Output 4 Blower Wye/Delta
6 Output 2,3,4,7,8 Common
7 Output 5 FWD
8 Output 5,6 Common
9 Output 6 REV
10 Output 7 Blower Wye/Delta
11 Output 8 NO Heat
12 Output 8 NC Heat
Table 7.5: Connector J11 Pinout
Pin Point Function
1 NTC 1
2 NTC 1
3 NTC 2
4 NTC 2
5 Analog out COM
6 Analog Out 0-10VDC
7 GND
8 24VDC
9 Digital Output
47
