Page 50

Shock Tuning / Stossdämpferabstimmung

Springs

Oil

Soft

(2) 1.3mm holes

Standard Pistons

Variable Rate Pistons

Less

More

Medium

(3) 1.2mm holes

Firm

(3) 1.1mm holes

AX80033

Dampening

Provides a different dampening rate depending on which direction you install.

Install this direction for faster
rebound and slower compression

Install this direction for Slower
rebound and faster compression

Provides the same dampening rate on both compression and extension

Depending on the application you may want a firmer spring than what is
included. Selecting a spring rate is based on each vehicles weight and handling
and usually will require some trial and error.

For rock crawling applications it is recommended to use a stiffer spring on
which ever corner is exhibiting torque twist.

Oils are another element you can use to tune the handling of your vehicle. You
want an oil that allows the vehicle to handle the terrain well, but not too thin as
to exhibit a springy bounce while driving.

We recommend starting with a good 30 wt. silicone oil. If you are looking for a
faster rebound/compression rate use a lower weight oil. If you are looking for a
slower rebound compression rate use a higher weight oil.

100wt.

10wt.

Springs

Oil

Soft

(2) 1.3mm holes

Standard Pistons

Variable Rate Pistons

Less

More

Medium

(3) 1.2mm holes

Firm

(3) 1.1mm holes

AX80033

Dampening

Provides a different dampening rate depending on which direction you install.

Install this direction for faster
rebound and slower compression

Install this direction for Slower
rebound and faster compression

Provides the same dampening rate on both compression and extension

Depending on the application you may want a firmer spring than what is
included. Selecting a spring rate is based on each vehicles weight and handling
and usually will require some trial and error.

For rock crawling applications it is recommended to use a stiffer spring on
which ever corner is exhibiting torque twist.

AX80033

AXA1069

AXA1041

AX30155

Installation

AX80033

AXA1069

AXA1041

AX30155

Installation

Faster

Slower

Dampening

100wt.

10wt.

AX04030

EXO Terra Buggy Body - .040" (Clear)

AX08103

2.2 3.0 Raceline Renegade Wheels - 41mm (Black) (2pcs)

AX08106

2.2 3.0 Raceline Renegade Wheels - 34mm (Black) (2pcs)

AX12017

2.2 3.0 Axial Hankook MT Tires 34mm - R35 Compound (2pcs)

AX12018

2.2 3.0 Axial Hankook MT Tires 41mm - R35 Compound (2pcs)

AX24260

AE-3 Vanguard ESC

AX24010

Brushless 2900KV Electric Motor

AX24206

Axial 2.4Ghz Radio System (2 Channel)

AX30031

Antenna

AX30112

Shock Diaphragm 13x4.5mm (6pcs)

AX30113

Rubber Bump Stop 3.6x7x4 (6pcs)

AX30147

Shock Shaft 3x53.5mm (2pcs)

AX30155

Axial Ti-Nitride Coated Shock Shaft 3x59.5 (2pcs)

AX30163

Pin 2.0x10mm (6pcs)

AX30170

Shaft 3 x 22 (2pcs)

AX30221

Spring 14x70mm 3.27 lbs/in - Firm (Yellow) (2pcs)

AX30229

Spring 14x54mm 4.33 lbs/in - Firm (Yellow) - (2pcs)

AX30366

Axle 5x35mm (2pcs)

AX30379

Dogbone Set 7x94mm (2pcs)

AX30381

EXO Heavy Duty Differential Output Shaft (2pcs)

AX30382

EXO Steering King Pin (TiN Coated) (2pcs)

AX30383

EXO Heavy Duty Differential Input Shaft (2pcs)

AX30384

EXO Steering Post Steel (Black) (2pcs)

AX30385

Diff Gasket 16x25x0.5mm (2pcs)

AX30390

Differential gear set

AX30392

Bevel Gear Set (38/13)

AX30408

Steel Input Shaft 5x29mm (2pcs)

AX30409

EXO Steering Rack Aluminum (Black)

AX30418

Dogbone Set 7x96mm (2pcs)

AX30424

EXO Center Driveline Dogbone Set (2pcs)

AX30427

Axial Narrow 12mm Aluminum Hub - Black (4pcs)

AX30566

Radio Box Gasket Set (3pcs)

AX30741

Spur Gear 32P 48 T

AX30742

Spur Gear 32P 50T

AX30743

Spur Gear 32P 52T

AX30744

Spur Gear 32P 54T

AX30799

EXO Bumper Skid Plates Aluminum (Front and Rear)

AX30800

EXO Adjustable Motor Mount System (Black)

AX30801

EXO Servo Saver Retaining Nut and Shaft (Black)

AX30802

EXO Rear Shock Tower Brace Set Aluminum (2pcs)

AX30806

EXO Servo Saver Spring - Firm

AX30808

EXO Battery Straps (Pair)

AX80002

Diff Case -Small

AX80005

Linkage Set

AX80006

Servo Set

AX80018

Hardware Parts Tree

AX80033

Axial 10mm Shock Parts Tree 1

AX80034

Axial 10mm Shock Parts Tree 2

AX80035

Axial 10mm Shock Caps Parts Tree

AX80036

Axial 72-103mm Shock Body

AX80091

EXO Bulkhead

AX80092

EXO Linkage Set

AX80093

EXO Tube Bumpers (Front and Rear)

AX80094

EXO Lower Rear Control Arms Set

AX80095

EXO Rear Wing and Vents

AX80096

67-90mm Shock Body Set

AX80097

EXO Shock Tower Set (Front and Rear)

AX80098

EXO Adjustable Battery Mount Set

AX80099

EXO Steering Knuckle Set

AX80100

EXO Chassis Guard and Toe Block Insert Set (Front and Rear)

AX80101

EXO Chassis Brace Set

AX80102

EXO Servo Saver Assembly

AX80103

EXO Rear Light Bezel and Radiator Set

AX80104

EXO Rear Hub Set

AX80105

EXO Chassis Component Mounts

AX80106

EXO Steering Knuckle Carrier Set

AX80107

EXO Radio Box and Electronic Component Mounts

AX80108

EXO Chassis Tub (Left and Right)

AX80109

EXO Cage Center Rear

AX80110

EXO Cage Center Top and Front

AX80111

EXO Lower Front Control Arms Set

AX80112

EXO Cage Lower Center

AX80113

EXO Cage Driver Side

AX80114

EXO Cage Passenger Side

AX80119

EXO RTR Links Parts Tree

AXA0093

M3x40mm Cap Head (Black) (10pcs)

877-642-9425 (877-64-Axial)
