Camber Link Basic Setup
AX80018
1
AX80018
1
AXA0128
AXA0128
AXA1053
AXA1053
AXA118
AXA118
AXA115
AXA1053
AXA1053
AXA0439
AXA1179
AXA1179
AXA0439
M3x20mm
x2
AXA1053
M3 Nylon Locking Hex Nut
x4
AXA118
M3x18mm
x4
EXO Machined Aluminum Rear Toe Block R1
(Hard Anodized)
AX30813
AXA115
M3x10mm
x2
AXA1053
M3 Nylon Locking Hex Nut (BLACK)
x2
AXA0128
M3x61mm Hex Socket Button Head Screw Shaft
x2
EXO Machined Aluminum Rear Toe Block R2
(Hard Anodized)
AX30814
*Requires AX80100 "1" & "2". See Spare Parts Bag.
AXA1179
O-Ring 2.5x1.5mm
x2
