Compaq AlphaStation XP1000 - Manual (Page 8)

QuickSpecs
Compaq AlphaStation XP1000
DA-10030 Canada — Version 17 — July 31, 2001 8
Options
Step 6 −−−− External Storage −−−− Optional (continued)
Step 6b – StorageWorks Model 42xx and 43xx Options
StorageWorks Model 42xx and 43xx Adapters/Controllers
• Storage controllers require a minimum operating system revision of Tru64 UNIX V4.0F or OpenVMS V7.1-2 unless noted otherwise.
• Each storage controller/adapter uses one PCI slot
Maximum # Supported
Tru64 UNIX OpenVMS
PCI 1-port Ultra2 SCSI (LVD) single-ended adapter, 68-pin HD connector, requires
BN38C cable (2 to 20m) to connect to single-ended UltraSCSI shelf – Model 42xx
only
1 1 SN-KZPCA-AA
68-pin HD male-to-VHDCI male UltraSCSI cable; required for each external UltraSCSI
shelf attached to KZPCA-AA adapter
BN38C-xx
PCI 2-channel LVD multimode Ultra3 adapter, VHDCI – Model 43xx only 1
V5.1
- 3X-KZPEA-DB
PCI 3-channel 64-bit Ultra2 LVD RAID controller, 64-MB cache 1 - DS-KZPCC-CE
StorageWorks Model 42xx and 43xx Universal Drive Shelves
Model 4254 (Ultra2 SCSI (LVD)
StorageWorks Model 4254 Ultra2 SCSI (LVD) split-bus universal drive shelf (Refer to
Compaq StorageWorks Enclosure 4200 QuickSpecs when configuring shelf)
When selecting a DS-SSL14-Rx split-bus shelf, order two 3X-KZPCA-AA adapters;
Model 4254 enclosures are compatible with Wide Ultra2 (LVD) adapters only
Note: The depth of a DS-SSL14-Rx shelf does not allow front and rear mounting, US
DS-SSL14-RS
Same as above, International DS-SSL14-R3
Same as above, Japan DS-SSL14-R4
Model 4314R (Ultra3 SCSI)
StorageWorks Model 4314R Ultra3 SCSI rackmount single bus universal drive shelf, US DS-SL13R-AA
Same as above, International DS-SL13R-AB
Same as above, Japan DS-SL13R-AJ
Model 4354 (Ultra3 SCSI)
StorageWorks Model 4354R Ultra3 SCSI rackmount dual bus universal drive shelf, US DS-SL13R-BA
Same as above, International DS-SL13R-BB
Same as above, Japan DS-SL13R-BJ
Model 4300 I/O Module (Ultra3 SCSI)
StorageWorks Model 4300 Ultra 160 SCSI single port LVD, I/O module DS-SE3ZJ-DA
StorageWorks Model 4300 Ultra 160 SCSI dual port LVD, I/O module DS-SE3ZJ-SA
9.1-GB Ultra2 (LVD) 7,200 rpm 1.0 ″ Universal drive 3R-A0525-AA Disk Drives (Supported in Model 42xx
and 43xx Universal Drive Shelves) 9.1-GB Ultra3 (LVD) 10,000 rpm 1.0 ″ Universal drive 3R-A0584-AA
9.1-GB Ultra3 (LVD) 15,000 rpm 1.0 ″ Universal drive 3R-A1542-AA
18.2-GB Ultra2 (LVD) 7,200 rpm 1.0 ″ Universal drive 3R-A0527-AA
18.2-GB Ultra3 (LVD) 15,000 rpm 1.0 ″ Universal drive 3R-A1543-AA
36.4-GB Ultra3 (LVD) 10,000 rpm 1.0 ″ Universal drive 3R-A0919-AA
Drive-height converter 4-pack 3R-A0528-AA
