QuickSpecs
Compaq AlphaStation XP1000
DA-10030 Canada — Version 17 — July 31, 2001 5
Options
Step 4 −−−− Memory
• Selection of a minimum of 256-MB memory is mandatory for CTO systems
• Systems support a maximum of 2-GB memory (two memory banks support four DIMMs per bank)
256-MB ECC memory DIMMs (4 x 64MB DIMMs) SN-MSP01-KB
512-MB ECC memory DIMMs (4 x 128MB DIMMs) SN-MSP01-KC
1024-MB ECC memory DIMMs (4 x 256MB DIMMs) SN-MSP01-KD
Step 5 −−−− Internal Storage
Step 5a −−−− SCSI Controllers −−−− Internal
• All systems include onboard UltraSCSI controller for internal disks only
• Systems support a maximum of two additional PCI storage adapters or RAID controllers for additional storage
Maximum # Supported
Tru64 UNIX OpenVMS
PCI single-channel UltraSCSI single-ended adapter (uses one PCI slot) 2 2 SN-KZPBA-CA
PCI single-channel UltraSCSI differential adapter (uses one PCI slot) 2 2 SN-KZPBA-CB
PCI 64-bit/66-MHz dual-channel wide Ultra3 SCSI adapter (uses one PCI slot) –
requires Ultra3 cable kit (3X-BN53A-01)
2
V5.1
- 3X-KZPEA-DB
PCI single-channel wide Ultra2 (LVD) adapter (uses one PCI slot) 1 1 SN-KZPCA-AA
Step 5b −−−− Internal Storage -- Disk Drives and Removable Media
• CTO systems require one mandatory hard disk drive
• Hard disk drive ordered with Tru64 UNIX or OpenVMS CTO systems includes factory installed software
• Systems support up to four hard disk drives:
- Two 3.5-inch x 1” hard disk drives in internal bays.
- Two 3.5-inch x 1.6” or 1” hard disk drives supported in the 5.25” removable media bays
SCSI Disk Drives 9.1-GB Ultra2 LVD Wide SCSI 7200 rpm 1” hard disk drive SN-PBXRW-SC
9.1-GB Ultra3 LVD Wide SCSI 10K rpm 1” hard disk drive SN-PBXRW-VB
18.2-GB Ultra2 LVD Wide SCSI 7200 rpm 1” hard disk drive SN-PBXRW-TB
18.2-GB Ultra3 LVD Wide SCSI 10K rpm 1” hard disk drive SN-PBXRW-WC
36.4-GB Ultra3 LVD Wide SCSI 10K rpm 1” hard disk drive SN-PBXRW-XB
Removable Media • Systems include one 5.25” 40X CD-ROM drive
• Systems support two additional 5.25”removable media devices (5.25” removable media bays also support
hard disk drives)
• Systems support additional ATAPI device
• DVD-ROM is data support only (no MPEG-2 capability)
• DVD-ROM is backward compatible with CD-ROM media
35/70-GB 8 mm AIT Wide SCSI internal tape drive SN-PBXTA-AA
50/100-GB 8 mm AIT Ultra2 (LVD) SCSI internal tape drive 3X-SZ50X-AA
12/24-GB 4 mm DAT internal SCSI tape drive, 1.6” front accessible bay SN-TLZ10-LK
20/40-GB 4 mm DAT Ultra2 (LVD) SCSI internal tape drive 3X-SD20X-AA
100-MB ATAPI ZIP drive SN-PBXRX-CA
6X/32X ATAPI DVD-ROM drive (data device only) SN-PBXRV-AA
